       Ultrasound Heart Phantom.


Computerized Imaging Reference Systems, Inc! For Cardiac Image Training

This CIRS Heart Phantom has completely anthropomorphic external and internal anatomy.



Features include:
Left/ right ventricles.
Left/right atriums.
Aortic valve.
Tricuspid valve.
Mitral valve.
Septums.
Aortic arch.
Papillary muscles.

The phantom is housed in a flexible PVC membrane, and embedded in a clear anechoic medium. All standard cardiac imaging planes are easily achieved.

This Heart Phantom is ideal for teaching and developing ultrasound examination skills and techniques as well as demonstrating 3D ultrasound capabilities.


Overall Dimensions:
13" X 10" X 5.5" (33cm X 25cm X 14cm)

Phantom Area:
8.5" X 6.5" X 4.0" (21.5cm X 16.5cm X 10cm)

Scanning Surface (Membrane):
30 gauge PVC Film.

Housing:
ABS Plastic.

Surrounding Soft Tissue:
Material: Zerdine® 1 solid elastic water-based polymer.
Freezing Point: 0°C
Melting Point: Above 100°C
Attenuation Coefficient: 0.07 dB/cm-MHz
Velocity of Sound Through Background Medium: 1540 m/s ± 10 m/s
Contrast: Anechoic.





Heart Shell:
Material: 1.2mm thermoplastic elastomer & urethane.
Contrast: Similar to human heart muscle.

Blood:
Material: Zerdine® 1 solid elastic water-based polymer.
Freezing Point: 0°C
Melting Point: Above 100°C
Attenuation Coefficient: 0.50 dB/cm-MHz
Velocity of Sound Through Background Medium: 1540 m/s ± 10 m/s
Contrast: Anechoic.

Muscle
Material: Zerdine® 1 solid elastic water-based polymer.
Freezing Point: 0°C
Melting Point: Above 100°C
Attenuation Coefficient: 0.50 dB/cm-MHz
Velocity of Sound Through Background Medium: 1540 m/s ± 10 m/s
Contrast: Similar to human heart muscle.



(1) US PATENT# 5196343


Stock #
Description
Your Price
067
Ultrasound Heart Phantom
$2,896.00
